USD8.00 - USD12.00
- Standard:ASTM
- Standard2:ASME B36.19M-2004
- Standard2:ASME B36.19M-1985
- Standard2:ANSI B36.10M-2004
- Standard2:ASME B36.10M-2004
- Grade Group:CrNi alloy
- Grade:Cr17Ni8
- Grade:1Cr13Mn9Ni1N
- Grade Group:Cr-Mo alloy
- Grade:15CrMo
- Section Shape:Round
- Place of Origin:CN;ZHE
- Application:Fluid Pipe
- Technique:Cold Drawn
- Alloy Or Not:Is Alloy
- Certification:ISO 9001 ISO14001 TS16949
- Surface Treatment:Hairline/ polished
- Special Pipe:Seamless Brass Tube
- Thickness:0.2 - 120 mm
- Outer Diameter(Round):2 - 914 mm
- Product name:Seamless Brass Tube
- Secondary Or Not:Non-secondary
- Model No:ASTM A270
- Type:Seamless
- Terms Of Trade:FOB, CIF
- Brand:Torich
- Certificate:IS9001
- MTC:EN10204 3.1 B EN10204 3.2B
- Application:Beer, beverages, diary
- Surface:Hairline/ Satin
ASTM B135 C27000 C27200 Seamless Brass Round Tube
ASTM B135 C27000 C27200 H58 Seamless Brass Round Tube
ASTM B135 C27000 C27200 Seamless Brass Round Tube
Application:residential housing water pipes, heating, cooling pipes installed aviation, aerospace,ships, military industry, metallurgy, electronics, electrical, mechanical, transportation,construction and other fields of the national economy.
Size Range:
OD: 2-914mm
WT: 0.2-120mm
Length: 2m,4m,5.8m,6m,12m or per customer’s request
Material:
Grade: C27000 C27200
Chemical Properties | ||||||
| Copper | Lead | Arsenic | Tin | Iron | Zinc |
C27000 | 63.0-68.5 | 0.09max | - | - | 0.07max | remainder |
C27200 | 62.0-65.0 | 0.07max | - | - | 0.05max | remainder |
Manufacture:
Pipes shall be made by the seamless process.
Mechanical Properties:
Mechanical Properties: | |||
| Standard | Tensile Strength (ksi) | Rockwell Hardness 30T |
C27000, C27200 | H58 | ≥ 54 | ≥ 30 |
Surface:
Mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required.
Packing:
Export standard package: bundled wooden box, suit for all kinds of transport,
or as required.
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample of ASTM A213 U Shaped seamless heat exchanger tube for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
ASTM B135 C27000 C27200 Seamless Brass Round Tube
