USD1200.00 - USD1500.00
- Standard:ASTM
- Standard2:ASTM A106-2006
- Standard2:ASTM A333-2005
- Standard2:ASME B36.10M-2004
- Standard2:ASTM A513-2007
- Standard:JIS
- Standard2:JIS G3462-2004
- Standard2:JIS G3452-2004
- Standard2:JIS G3458-2005
- Standard2:JIS G3467-2006
- Standard2:JIS G3464-2006
- Standard2:JIS G3465-2006
- Grade Group:10#-45#
- Grade:10#
- Grade:45#
- Grade Group:16Mn
- Grade:16Mn
- Grade Group:ST35-ST52
- Grade:ST35
- Grade:St52
- Section Shape:Round
- Place of Origin:CN
- Technique:Cold Drawn
- Special Pipe:Thick Wall Pipe
- Alloy Or Not:Non-alloy
- Tolerance:±10%
- Type:Seamless Steel Pipe
- Processing Service:Cutting
- Thickness:5 - 50 mm
- Outer Diameter(Round):20 - 300 mm
- Certification:ISO
- Surface Treatment:Anti Rust Oil
- Product name:China Wholesaler Heavy Thick Wall 15Mo3 Seamless Steel Pipe
- Type:Seamless Steel Pipe
- Certification:ISO9001 TS 16949 ISO14001
- OD:20 - 300 mm
- WT:5 - 50 mm
- Length:3-12m
- Cross-Section Shape:Round
- Terms of Trade:FOB,CFR,CIF
- Place of Origin:Zhejiang, China
- Brand:TORICH
China Wholesaler Heavy Thick Wall 15Mo3 Seamless Steel Pipe
Outside Diameter: 20 – 300 mm
Wall Thickness: 5– 25 mm
Tolerances:
OD:
D 5 – 10 mm: ± 0.15 mm
D 11 – 30 mm: ± 0.30 mm
D 32 – 50 mm: ± 0.40 mm
D 51 – 140 mm: ± 0.8%
WT:
S 0.4 – 1 mm: ± 0.12 mm
S 1.2 – 5 mm: ± 10%
S 5.5 – 12 mm: ± 8%
Quality Assurance: ISO 9001&PED 97/23/EC certificated with 100% traceability on all instrument tubes and material test reports(EN 10204/3.1B)accompany every shipment upon request.
Application:
Instrument Tubing
Chromatography tubing
Hydraulic Tubing
High Pressure Tubing
Cleaned Tubing
Multi Core Tubing
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of stainless steel pipe ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
