USD1000.00 - USD1500.00
- Standard:ASTM
- Standard2:ASTM A335M-2006
- Grade Group:10#-45#
- Grade:10#
- Grade:20#
- Grade:45#
- Grade Group:16Mn
- Grade:16Mn
- Section Shape:Round
- Technique:Cold Drawn
- Special Pipe:Thick Wall Pipe
- Alloy Or Not:Non-alloy
- Tolerance:±10%
- Type:Seamless Steel Pipe
- Processing Service:Punching
- Processing Service:Cutting
- Place of Origin:CN;ZHE
- Thickness:1 - 50 mm
- Outer Diameter(Round):6 - 420 mm
- Application:High temperature service
- Certification:ISO9001, ISO14001, TS16949
- Surface Treatment:Oiled
- Product name:8 inch SA335 P1 P2 P5 P9 P11 P22 Steel Pipe Bevel End for Sale
- Keyword:SA335 P11 Steel Pipe
- Standard:ASTM A335
- Surface:Oiled
- Shape:Square/ Rectangular
- Delivery condition:+C/+A
- Type:Seamless
- Production:Cold Drawn
- Usage:Boiler, Heat Exchanger
- MTC:EN10204 3.1 B
TORICH 8 inch SA335 P1 P2 P5 P9 P11 P22 Steel Pipe Bevel End for Sale
ASTM A335 Seamless ferritic and alloy steel pipe for high temperature service
Applications: for Boilers,Superheaters,Heat-Exchangers
Size range: O.D.:6-420mm W.T.:1-50mm L: according to customer requirement
Steel Grade and Chemical Compositions: | |||||||
Steel Grade | C | Mn | P | S | Si | Cr | Mo |
max | max | max | max | max | min |
| |
P5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 4.00-6.00 | 0.45-0.65 |
P9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 |
P11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 |
P12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
P21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 2.65-3.35 | 0.80-1.06 |
P22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
P91 | 0.08-0.12 | 0.30-0.60 | 0.020 | 0.010 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 |
P92 | 0.07-0.13 | 0.30-0.60 | 0.020 | 0.010 | 0.50 | 8.50-9.50 | 0.30-0.60 |
Steel Grade | Tensile Strength | Yield Strength | Elongation | Hardness.Max |
|
min.ksi [Mpa] | min.ksi [Mpa] | % | Brinell/Vickers | Rockwell | |
P1, P2 | 55[380] | 30[205] | 20 |
|
|
P12 | 60[415] | 32[220] | 20 |
|
|
P23 | 74[510] | 58[400] | 20 |
|
|
P91 | 85[585] | 60[415] | 30 | 250 HB/265 HV | 25 HRC |
P92, P911 | 90[620] | 64[440] | 30 | 250 HB/265 HV | 25 HRC |
P122 | 90[620] | 58[400] | 30 | 250 HB/265 HV | 25 HRC |
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample of 304 316 Stainless steel Seamless square tube for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
TORICH 8 inch SA335 P1 P2 P5 P9 P11 P22 Steel Pipe Bevel End for Sale
