USD1000.00 - USD4000.00
- Place of Origin:CN;ZHE
- Alloy Or Not:Is Alloy
- Grade:A213
- Grade:A335 P1
- Grade:A335 P11
- Grade:A335 P12
- Grade:A335 P5
- Grade:A335 P9
- Grade:A335 P91
- Grade:A335 P92
- Thickness:1 - 50 mm
- Outer Diameter(Round):6 - 420 mm
- Secondary Or Not:Non-secondary
- Standard2:ASTM A213-2001
- Standard2:ASTM A213M-2001
- Standard2:ASTM A335-2006
- Application:Boiler Pipe
- Technique:Cold Drawn
- Grade Group:A53-A369
- Standard:ASTM
- Section Shape:Round
- Surface Treatment:oil
- Special Pipe:boiler tubes
- Certification:ISO
- Product name:ASTM A335 p1 p2 p5 p9 p11 p22 p91 t12 t1 t91
- Keywords:alloy steel pipe
- Brand Name:Torich
- Model Number:ASTM A213 A335
- End protector:Plain
- Length:1-12m
- Type:SMLS
- Shape:Round Shape
- Production Method:Cold drawn
- MTC:En10204.3.2B
34crmo4 alloy steel pipe
ASTM A335 p1 p2 p5 p9 p11 p22 p91 t12 t1 t91/A213 T1 T2 T5 T9 T11 T12 T22 T23 T91 Alloy
ASTM A335 Seamless ferritic and alloy steel pipe for high temperature service
ASTM A213 ASME SA213 Seamless Alloy Carbon Steel Heat Exchanger Tubes
Applications: for Boilers,Superheaters,Heat-Exchangers
Size range: O.D.:6-420mm W.T.:1-50mm L: according to customer requirement
| Steel Grade and Chemical Compositions: | |||||||
| Steel Grade | C | Mn | P | S | Si | Cr | Mo |
| max | max | max | max | max | min | ||
| P5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 4.00-6.00 | 0.45-0.65 |
| P9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 |
| P11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 |
| P12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
| P21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 2.65-3.35 | 0.80-1.06 |
| P22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
| P91 | 0.08-0.12 | 0.30-0.60 | 0.020 | 0.010 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 |
| P92 | 0.07-0.13 | 0.30-0.60 | 0.020 | 0.010 | 0.50 | 8.50-9.50 | 0.30-0.60 |
| Steel Grade | Tensile Strength | Yield Strength | Elongation | Hardness.Max | ||
| min.ksi [Mpa] | min.ksi [Mpa] | % | Brinell/Vickers | Rockwell | ||
| P1, P2 | 55[380] | 30[205] | 20 | |||
| P12 | 60[415] | 32[220] | 20 | |||
| P23 | 74[510] | 58[400] | 20 | |||
| P91 | 85[585] | 60[415] | 30 | 250 HB/265 HV | 25 HRC | |
| P92, P911 | 90[620] | 64[440] | 30 | 250 HB/265 HV | 25 HRC | |
| P122 | 90[620] | 58[400] | 30 | 250 HB/265 HV | 25 HRC | |
ASTM A335 p1 p2 p5 p9 p11 p22 p91 t12 t1 t91/A213 T1 T2 T5 T9 T11 T12 T22 T23 T91 Alloy
| Steel Grade and Chemical Compositions: | |||||||
| Steel Grade | C | Mn | P | S | Si | Cr | Mo |
| max | max | max | max | max | min | ||
| T5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.5 | 4.0-6.0 | 0.45-0.65 |
| T9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.0-10.0 | 0.90-1.10 |
| T11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.0-1.50 | 0.44-0.65 |
| T12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
| T21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 2.65-3.35 | 0.80-1.06 |
| T22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
| Steel Grade | Tensile Strength | Yield Strength | Elongation | Hardness.Max | ||
| min.ksi [Mpa] | min.ksi [Mpa] | % | Brinell/Vickers | Rockwell | ||
| T5b | 60[415] | 30[205] | 30 | 179HBW/190HV | 89HRB | |
| T9 | 60[415] | 30[205] | 30 | 179HBW/190HV | 89HRB | |
| T12 | 60[415] | 32[220] | 30 | 163HBW/170HV | 85HRB | |
| T91 | 85[585] | 60[415] | 20 | 250HBW/265HV | 25HRC | |
| T92 | 90[620] | 64[440] | 20 | 250HBW/265HV | 25HRC | |
ASTM A335 p1 p2 p5 p9 p11 p22 p91 t12 t1 t91/A213 T1 T2 T5 T9 T11 T12 T22 T23 T91 Alloy
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample of ASTM A335 p1 p2 p5 p9 p11 p22 p91 t12 t1 t91/A213 T1 T2 T5 T9 T11 T12 T22 T23 T91 Alloy for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
