USD1000.00 - USD4000.00
- Place of Origin:CN;ZHE
- Grade:13CrMo44
- Grade:13CrMo45
- Thickness:1 - 50 mm
- Outer Diameter(Round):6 - 420 mm
- Grade Group:Cr-Mo alloy
- Secondary Or Not:Non-secondary
- Technique:Cold Drawn
- Application:Structure Pipe
- Standard2:GB/T 3639-2000
- Section Shape:Round
- Standard:GB
- Alloy Or Not:Is Alloy
- Surface Treatment:oil
- Certification:ISO
- Special Pipe:alloy steel pipe
- Product name:Seamlesswelded low temp 13crmo4-5 alloy steel pipe
- Keywords:13crmo4-5 alloy steel pipe
- Brand Name:Torich
- Model Number:GB/T 3639
- End protector:Plain
- Type:SMLS
- Length:1-12m
- Material:Alloy
- Production Method:Cold drawn
- MTC:En10204.3.2B
13crmo4-5 alloy steel pipe
Seamless welded low temp 13crmo4-5 alloy steel pipe
Size: OD6-420 mm
WT1-50mm
Production method: Cold drawn ,Cold rolled,Hot rolled etc
Heat treatment:SR A QT etc as per requests,Pls advise specification
Packaging: In bundles or in wooden boxes packaging.
Seamless welded low temp 13crmo4-5 alloy steel pipe
Mechanical properties:
Standrad | Steel grade | Tensile strength(MPa) | Yield strength(MPa) | Alongation(%) | Hardness |
15Mo3 | 450~600 | ≥270 | ≥22 | / | |
13CrMo44 | 440~590 | ≥290 | ≥22 | / | |
13CrMo45 | 450-600 | ≥300 | ≥19 | / | |
10CrMo910 | 480~630 | ≥280 | ≥20 | / |
Seamless welded low temp 13crmo4-5 alloy steel pipe
Chemical composition:
Standrad | Steel grade | Chemical composition(%) | ||||||||||
Steel grade | C | Si | Mn | P | S | Cr | Mo | Cu | Ni | V | Al | W |
15Mo3 | 0.12~0.20 | 0.10~0.35 | 0.40~0.80 | ≤0.035 | ≤0.035 | 0.25~0.35 | ||||||
13CrMo44 | 0.10~0.18 | 0.10~0.35 | 0.40~0.70 | ≤0.035 | ≤0.035 | 0.70~1.10 | 0.45~0.65 | |||||
13CrMo45 | 0.08-0.18 | ≤0.35 | 0.4-1.00 | ≤0.025 | ≤0.010 | 0.70-1.15 | 0.40-0.60 | ≤0.30 | N≤0.12 | |||
10CrMo910 | 0.08~0.15 | ≤0.50 | 0.30~0.70 | ≤0.025 | ≤0.020 | 2.00~2.50 | 0.90~1.10 | ≤0.30 | ≤0.30 | ≤0.015 |
SeamSeamless welded low temp 13crmo4-5 alloy steel pipe less welded low temp 13crmo4-5
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample of Seamless welded low temp 13crmo4-5 alloy steel pipe for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
