TORICH DIN 17200 CK45 SAE 1045 Spring Steel Tube
price
USD900.00 - USD2000.00
FOB
5 tons
6000tons / Year
Shanghai
Quantity
- Standard:ASTM
- Standard2:ASTM A513-2007
- Standard:DIN
- Standard2:DIN 2391
- Standard2:DIN EN 10305
- Standard:GB
- Standard2:GB/T 3639-2000
- Grade Group:10#-45#
- Grade:10#
- Grade:20#
- Grade:45#
- Grade Group:ST35-ST52
- Grade:St37
- Grade:St52
- Grade:St35.8
- Grade:St37-2
- Grade:St35.4
- Grade:St52.4
- Grade:ST35
- Grade:ST37.4
- Grade Group:Cr-Mo alloy
- Grade:30CrMo
- Section Shape:Round
- Technique:Cold Drawn
- Alloy Or Not:Non-alloy
- Tolerance:±10%
- Type:Seamless Steel Pipe
- Processing Service:Bending
- Processing Service:Welding
- Processing Service:Cutting
- Place of Origin:CN;ZHE
- Thickness:0.5 - 4 mm
- Outer Diameter(Round):12 - 128 mm
- Application:Mechanical purpose
- Certification:ISO 9001 TS16949 ISO 14001
- Surface Treatment:Oiled
- Special Pipe:SSID Tube
- Product name:Spring Steel Tube
- Material:1045
- Type:Gas Spring Tube
- Secondary Or Not:Non-secondary
- Length:1-12m
- Delivery Condition:+N, +SRA, +C
- Surface:Oiled
- Heat Treatment:Bright Annealing
- Usage:Auto and Moto Parts
- End protector:Plastic Pipe Cap
TORICH DIN 17200 CK45 SAE 1045 Spring Steel Tube
TORICH DIN 17200 CK45 SAE 1045 Spring Steel Tube
Quick Detail:
| Product name | TORICH DIN 17200 CK45 SAE 1045 Spring Steel Tube |
| Steel Grade | CEW 1008, 1010, 1020, St37.2, E355 |
| Size Range | OD range:15-200mm WT range: 0.8-16mm |
| Tolerance | OD: (+/-0.06mm) WT: (+/-0.03mm) |
| ID surface | 0.4μm |
| Straightness | ≤0.5mm/1m |
| Roundness | ≤0.5mm |
| Regular specifications | 23.2X1.6, 42X3, 25.4X0.9, 15x1, 19x1.5, 20x1, 20x1.5 |
| Standard | DIN 2393, ASTM-A513-t6, EN10305, ASTM A519, GOST 5005 -82, DIN2394, JIS-G3445, DIN2391 BS6323, GOST8734-75, IS3074, ASTM A513 |
| Application | Motorcycle front fork, Motor outer shell, Automobile shock absorber cylinder, Dust cover, Automobile shock absorber reservior, refrigaretion gas reservior |
| Production process | Material incoming inspection Surface treatment,Cold rolling Inspection,Rust preventive work,Warehouse storage |
Our technical team can assist on the specification of your gas spring or damper product to ensure that the optimal product is selected or developed for your application.
