USD1000.00 - USD1200.00
- Standard:ASTM
- Standard2:ASTM A213-2001
- Standard2:ANSI A213-2001
- Standard2:ASTM A335-2006
- Standard2:ASTM A179-1990
- Standard2:ASTM A199
- Grade Group:10#-45#
- Grade:10#
- Grade:20#
- Section Shape:Round
- Place of Origin:CN;ZHE
- Application:Boiler Pipe
- Technique:Cold Drawn
- Alloy Or Not:Non-alloy
- Tolerance:±10%
- Type:Seamless Steel Pipe
- Processing Service:Bending
- Processing Service:Punching
- Processing Service:Cutting
- Thickness:2.2 - 25.4 mm
- Outer Diameter(Round):12.7 - 177.8 mm
- Certification:ISO 9001:2008 , TS16949
- Surface Treatment:anti-rust oiled
- Special Pipe:Seamless Cold-Drawn Pipe
- Product Name:Seamless Carbon Steel Tube
- Standard:SA179 SA192 SA213 SA335
- Material:A179, A192, 1010, 1020, T11, T22
- Usage:For Boilers/Heat Exchangers/Condensers
- Surface:anti-rust oiled
- Shape:Round Shape
- length:3-12M
- End protector:Plain
- MTC:En10204.3.2B
- Type:Cold Drawn
TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Carbon Cold Formed Steel Hollow Tube
TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Carbon Cold Formed Steel Hollow Tube
Applications:
- For Boilers,
- Superheaters,
- Tubular Heat-Exchangers,
- Condensers
- Heat transfer apparatus
U bend Tubes according to Customer request
Material:Low Carbon Steel
Production: Seamless Cold Drawn
Size range:O.D.:12.7 - 177.8 mm W.T.:2.2 - 25.4 mm L: according to customer requirement.
Steel Grade and Chemical Compositions:
| C | 0.06-0.18 |
| Mn | 0.27-0.63 |
| P | ≤0.035 |
| S | ≤0.035 |
Mechanical Properties
| Tensile Streghth | min ksi[Mpa] 47[325] |
| Yield Point | min ksi[Mpa] 26[180] |
| Elongation | ≥35% |
| Hardness | ≤72HRB |
Heat Treatment:
Tubes are heat treated after the final cold draw pass at a temperature of 1200℉(650℃) or higher
Surface Finish:
Finish Tubes are free of scale.
We have normal heat treatment annealing with black surface.
Have bright annealing with grey and bright surface.
Application
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Carbon Cold Formed Steel Hollow Tube
