TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Pipe and Tube

• Standard:ASTM
• Standard2:ASTM A213-2001
• Standard2:ANSI A213-2001
• Standard2:ASTM A335-2006
• Standard2:ASTM A179-1990
• Standard2:ASTM A199
• Grade Group:10#-45#
• Grade:10#
• Grade:20#
• Section Shape:Round
• Place of Origin:CN;ZHE
• Application:Boiler Pipe
• Technique:Cold Drawn
• Alloy Or Not:Non-alloy
• Tolerance:±10%
• Type:Seamless Steel Pipe
• Processing Service:Bending
• Processing Service:Punching
• Processing Service:Cutting
• Thickness:2.2 - 25.4 mm
• Outer Diameter(Round):12.7 - 177.8 mm
• Certification:ISO 9001:2008 , TS16949
• Surface Treatment:anti-rust oiled
• Special Pipe:Seamless Pipe and Tube
• Product Name:TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Pipe and Tube
• Standard:SA179 SA192 SA213 SA335
• Material:A179, A192, 1010, 1020, T11, T22
• Usage:For Boilers/Heat Exchangers/Condensers
• Surface:anti-rust oiled
• Shape:Round Shape
• length:3-12M
• End protector:Plain
• MTC:En10204.3.2B
• Type:Cold Drawn

TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Pipe and Tube TORICH SA179 SA192 SA213 SA335 AISI 1020 Seamless Pipe and Tube

Applications:

• For Boilers,
• Superheaters,
• Tubular Heat-Exchangers,
• Condensers
• Heat transfer apparatus

U bend Tubes according to Customer request

Material:Low Carbon Steel

Production:  Seamless Cold Drawn

Size range:O.D.:12.7 - 177.8 mm    W.T.:2.2 - 25.4 mm     L: according to customer requirement.

Steel Grade and Chemical Compositions:

Mechanical Properties

Heat Treatment:

Tubes are heat treated after the final cold draw pass at a temperature of 1200℉(650℃) or higher

Surface Finish:

Finish Tubes are free of scale.

We have normal heat treatment annealing with black surface.

Have bright annealing with grey and bright surface.

click it to know more

Application
